Figures 2017_12_13 (TH)

[DiVe]

Dear colleagues,

according to the outcome of the task force meeting, i have reworked the TH figures:

- splitted Calvicle IN/OU
- added THSP 01/12 AV X/Y/Z
- re-arranged standard and additional measurements

ISO-TH_20171213.pdf

(173.43 KiB) Downloaded 659 times

Find also the current working list for standard/additional instrumentation:

2017_12_13_THOR_Standard_Additional.xlsx

(21.62 KiB) Downloaded 630 times

also I changed some details:
- added a 7th rib to the figure
- repositioned location for chest deflection on 3rd, 6th rib


The next step will be to prepare additional slides for the T3 variant "THOR Europe".

So stay tuned

Bye,
Dirk
